Voilamart 20" Electric Bicycle Bike Conversion Kit 48V 1000W Rear Wheel LCD E-Bike Cycling Hub (Thumb Throttle)

This Electric Bicycle kit includes everything needed(except battery) to convert your standard bike into a top-of-the-line performance electric bike, which delivers unequaled performance and reliability. You’ll be out cruising along at 28 mph (45km/h) without a sweat!

Key feature:

* Built to the highest international standards, CE

* 48V 1000W and 250W super power brushless gearless hub motor

* Restricted to 250W and 16 mph by default as a road-legal kit

* Nylon tire& alloy rim& galvanized steel spoke

* Rare-earth metal magnet are used in the motor to efficiently produce large power

* Aluminum alloy powerful controller guarantee big current supply

* Adjustable 5 level intelligent pedal assist with LCD

* LCD display shows battery level and pedal assistance settings

* Brake Levers cut off the power supply to the motor safely

* Crank speed sensor for 8 Point High Efficent Pedal Assist

* Aluminum alloy powerful controller

Upgraded Intelligent Motor Controller:

* Allow you to swap two power modes between the full 1000W power or 250W power by a single blue switch wire is embedded in controller.(Only for Throttle)

* Still remain the full 1000W power with no speed control.(Only for Pedal Assist System,"PAS")

Note:

1.The system requires a 48 Volt electrokinetic cell battery with a nominal capacity not less than 11.6Ah.

2.Battery and charger are not included in package.

3.The AU regulations dictate that a kit must not exceed the rated power of 250W to be road-legal!

So please connecting the Road-legal Switch Wire and disconnect the PAS on Road.

Caution: For your Safety, Please turn off the battery before connecting the Controller!

SPECIFICATIONS:

Wheel type: Rear Wheel

Motor: Brushless Gearless

Power: 1000W / 48V or 250W / 48V

Spokes: Steel, 12G×2.6mm, 36pcs

Tire Material: Nylon

Rim Material: Alloy Double Wall

Wheel Size: 20" (508mm)

Rim Diameter: 17.12" (435mm)

Rear Dropout: 5.3" (135mm)

Wheel Axle: 8.3" (210 x Φ10mm)

Compatiable Disc: 160mm

Torque: 45 N.M

Net weight: 10.5kg

Max speed: 28 mph or 16 mph

Max load capacity: 200kg

Package Include:

1x Brushless Gearless Motor Rear Wheel

1x Intelligent Motor Controller

1x Pedal Assist Crank Sensor

1x Cable Ties & Plastic Coil

1x Pair of Handle Bars (included Throttle)

1x Controller Bag

1x Pair of Brake Handles

1x LCD Meter

1x 7 Speed Freewheel

1x Manual

1x Tyre (Not Installed)
